How To Replace Touch Panel of Samsung Phone

This article covers how you can change the touch panel on your Samsung phone. So, read it completely to know the tools and techniques you need to learn to do it yourself.



Most new cellphone designs now use visual sticky to connect the LCDs, digitizers, and cup lens, significance when anyone smashes all three need to be changed. Changing the cup only is almost difficult without expert help. However, it can be done with the right resources.

how to replace touch screen of mobile
mobile touch panel repair

Below we will display one procedure to execute this process yourself. This procedure performs well on damaged displays for the Samsung phones sequence, such as the Samsung Galaxy SII, SIII, and S4 as well as the Samsung A, S, J, M, and N Series. Be very cautious replacing your cup display, even with the most expert devices you will only have a 70% achievement amount.

How to Replace lcd touch panel on the Smartphones
How to Replace Only the Glass on the Smartphones


What you need to replace your touch panel on Samsung Phones

Smartphones Glass touch panel lcd
Smartphones Glass touch panel mobile phone


Items:

• Damaged Digitizer and LCD display assembly
• Alternative Glass Screen
• Optical Obvious Adhesive

Alternative Glass lcd panel Screen
Alternative Glass LCD Panel


Tools:
• Roller
• Molybdenum Wire
• Hot Plate
• Gloves
• Autoclave

optical glue mobile repair adhesive LCD touch refurbishment
refurbished adhesive touch

The molybdenum Sequence which can take a position in high heat range ranges without growing and dropping durability is used to securely define away the sticky between the cup and the digitizer without making any of the beginning represents. A new part of a visual clear sticky is used to protect the new cap back on. The hot dish is used to heat up the sticky. If you don’t have a hot dish, you might be able to use a blow clothing dryer, but be very cautious not to get too hot in the setup and harm the LCD. The curler device can help connect the sticky making little air pouches. An autoclave is also used to make sure an ideal complete with no air remaining between the cup and digitizer.

electronic hot plate for smart phones lcd touch
electronic hot plate for phones touch

read Samsung feature phone article to learn more about the best Samsung feature phone main parts with all the latest features and innovations available to full fill your needs this year

Download Samsung schematic diagram pdf here to repair Samsung galaxy mobiles

Step 1 – Warm up the broken setup on the hot plate

Set the heat range to 60°C and also heat the set up until it’s hot. How long it requires to heat is determined by your heating unit and the destruction to your display. You will have to experience it in the next phase.
Warm up the broken smartphone touch with hot plate
hot plate for broken smartphone LCD

Step2–Individual broken cup from digitizer use Molybdenum string

Attach one end of the molybdenum string to something protected. On the other end, you can keep or affix to another protected item. Dressed in safety gloves as the set up will be hot, pitching wedge the string between the broken cup and digitizer while properly shifting the set up in a cutting movement. If there is too much level of resistance it may need to be warmed for more time. Keep doing this until you have eliminated all the cups.

Eliminate any left over adhesive
Eliminate smartphone's touch adhesive

Step 3 – Eliminate any left-over adhesive

It is necessary to get rid of any sticky still trapped on the display. We suggest using some kind of digital washing remedy to be able not harm the digital elements.

Step 4 – Position the dual on the sides adhesive

Peel one part of the sticky and put it on the digitizer in the middle. Next, use a shifting device to create sure it is limited. Next, remove the other part of the sticky and properly put the LCD based on top, don’t put it upside-down! Implement stress to create sure it’s limited.

Click here To know what is micro soldering on Samsung Phones

The Sanwa multimeter circuit diagram is one of the best ways to know how to use a multimeter. By reading the blog post, you can learn the multimeter working principles and download information that can help you with the parts of a digital multimeter.

Step 5 – Eliminate the left-over air bubbles

For best outcomes, the recently constructed cup and gadgets must then be placed in a commercial autoclave to get rid of all left-over air pouches. More compact machine gadgets have also been revealed to provide effective outcomes.
The end outcome is a percolate-free setup.
From the above-mentioned guide, you can understand how to split up the cup from the digitizer and LCD for Samsung phones sequence, S2 designs, S3 designs, Universe S4, Observe I and Observe II designs, and other AMOLED displays, as well as some other mobile phones using complete cup glues. BUT THIS PROCESS IS RECOMMENDED FOR PROFESSIONALS ONLY. Also, you can find the Glass Screen Only Alternative Movie on Youtube. com and the Samsung phone replacement areas from mobile repairing online:


Download motherboard chip level repairing guide pdf to repair Samsung phones

Read on to learn how to fit a replacement smartphone display click here

by reading this blog post now you know everything about How To Replace Touch Panel of Samsung Phones tools and techniques to do it yourself. text me your question in the comment box if you want to learn anything about Replacing Touch Screen
